Energy Monitoring
Track the real-time energy consumption of essential devices-such as refrigerators, freezers, heaters, or indoor PV systems. Identify high-energy consumers and optimize their usage without risking accidental shutdown. <FIGURE class=„image image_resized“></FIGURE>
Usage Analysis
Monitor your energy consumption trends over time to make informed decisions about appliance usage and identify opportunities to upgrade to more energy-efficient models. <FIGURE class=„image image_resized“></FIGURE>
Overload Detection & Instant Notifications
Protect your appliances and electrical system by receiving alerts when a connected device exceeds its safe power threshold. Avoid overheating, prevent potential damage, and maintain operational safety with proactive monitoring. <FIGURE class=„image image_resized“></FIGURE>
Cost Estimation
Understand the real cost of running each appliance. Shelly Plug PM Gen3 provides valuable consumption data to help you estimate monthly operational costs-giving you control over budgeting and energy expenses. <FIGURE class=„image image_resized“></FIGURE>
Specifications Physical
Size (HxWxD):
44×44×70 ±0.5 mm / 1.73×1.73×2.75 ±0.02 in
Weight:
48 ±1 g / 1.69 ±0.04 oz
Compatible sockets:
CEE 7/1, CEE 7/3 (Type F / Schuko) or CEE 7/5 (Type E)
Compatible plugs:
CEE 7/2, CEE 7/4 (Type F / Schuko), CEE 7/7, CEE 7/16 (Type C) or CEE 7/17
Shell material:
Plastic
Environmental
Ambient temperature:
- 20 °C to 40 °C / –5 °F to 105 °F
Humidity
30 % to 70 % RH
Max. altitude
2000 m / 6562 ft
Glow-wire temperature:
750°C
Pollution degree:
2
Required forced cooling:
No
Electrical
Power supply:
230 V~ 50 Hz
Power consumption:
< 1 W
Rated impulse-withstand voltage:
2500 V
Max. current:
16 A
Output circuits ratings
Max. output power:
3680 W (resistive load only)
Overvoltage category:
II
Sensors, meters
Internal-temperature sensor:
Yes
Voltmeter (AC):
Yes
Ammeter (AC):
Yes
Power and energy meters:
Yes
Wi-Fi
Protocol:
802.11 b/g/n
RF band:
2412–2484 MHz
Max. RF power:
<10 dBm
Wi-Fi Range:
–
Microcontroller unit
CPU:
ESP-Shelly-C38F
Flash:
8 MB
Firmware capabilities
Webhooks (URL actions):
20 with 5 URLs per hook
Scripting:
Yes
MQTT:
Yes
