Параметри и описание
Product benefits
- Robust, yet light and compact design
- Safe and very uniform illumination, due to frosted and tempered glass diffuser
- No upper light output ratio (ULOR 0%) when mounted at 0° tilt
- Energy savings of up to 90 % compared to halogen lamp floodlights
Areas of application
- Replacement for floodlights with halogen lamps
- Outdoor use (IP65)
- Public areas
- Building facades
- Gardens, balconies and other outdoor areas
- Construction areas
Product features
- Reflector-based, symmetric light distribution with 100° x 100° beam angle
- Surge protection: up to 4 kV (L/N-PE), 2 kV (L-N)
- Mounting bracket with 30° angle and wide rotation area
- Pre-installed, flexible 1 m cable (H05RN-F), wrapped 3 × 1.0 mm² single wires
- Breather membrane to optimize air exchange, without compromising IP protection
Safety advice
- Max. wind load surface 0.043 m²
- All electrical connections must be made by a qualified person.
- The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire shall be destroyed.
- Terminal block not included. Installation must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Specifications
Electrical data <FIGURE class=„table“><TABLE><TBODY><TR><TD>Nominal wattage</TD><TD>90.00 W</TD></TR><TR><TD>Nominal voltage</TD><TD>220…240 V</TD></TR><TR><TD>Mains frequency</TD><TD>50…60 Hz</TD></TR><TR><TD>Nominal current</TD><TD>434 mA</TD></TR><TR><TD>Inrush current</TD><TD>7.9 A</TD></TR><TR><TD>Inrush current time Th50</TD><TD>1.9 µs</TD></TR><TR><TD>Max. number of luminaires per miniature circuit breaker B16</TD><TD>20</TD></TR><TR><TD>Max. number of luminaires per miniature circuit breaker C10</TD><TD>15</TD></TR><TR><TD>Max. number of luminaires per miniature circuit breaker C16</TD><TD>23</TD></TR><TR><TD>Power factor λ</TD><TD>> 0.90</TD></TR><TR><TD>Total harmonic distortion</TD><TD>< 20 %</TD></TR><TR><TD>Protection class</TD><TD>I</TD></TR><TR><TD>Operating mode</TD><TD>Integrated LED driver</TD></TR></TBODY></TABLE></FIGURE> Photometrical data <FIGURE class=„table“><TABLE><TBODY><TR><TD>Luminous flux</TD><TD>9000 lm</TD></TR><TR><TD>Luminous efficacy</TD><TD>100 lm/W</TD></TR><TR><TD>Color temperature</TD><TD>4000 K</TD></TR><TR><TD>Light color (designation)</TD><TD>Cool White</TD></TR><TR><TD>Color rendering index Ra</TD><TD>≥80</TD></TR><TR><TD>Standard deviation of color matching</TD><TD>< 5 sdcm</TD></TR><TR><TD>Luminous intensity</TD><TD>-</TD></TR><TR><TD>Low flicker</TD><TD>Yes</TD></TR><TR><TD>Flickering metric (Pst LM)</TD><TD>-</TD></TR><TR><TD>Stroboscope effect metric (SVM)</TD><TD>-</TD></TR><TR><TD>Photobiological safety group acc. to EN62778</TD><TD>RG1</TD></TR><TR><TD>Photobiological safety group acc. to EN62471</TD><TD>RG1</TD></TR><TR><TD>Beam angle</TD><TD>100 ° x 100 °</TD></TR></TBODY></TABLE></FIGURE> Dimensions & Weight <FIGURE class=„table“><TABLE><TBODY><TR><TD>Length</TD><TD>236.00 mm</TD></TR><TR><TD>Height</TD><TD>40.00 mm</TD></TR><TR><TD>Width</TD><TD>255.00 mm</TD></TR><TR><TD>Product weight</TD><TD>1520.00 g</TD></TR><TR><TD>Cable length</TD><TD>1000 mm</TD></TR></TBODY></TABLE></FIGURE> Materials & Colors <FIGURE class=„table“><TABLE><TBODY><TR><TD>Product color</TD><TD>Black</TD></TR><TR><TD>Housing color</TD><TD>Black</TD></TR><TR><TD>Body material</TD><TD>Aluminum</TD></TR><TR><TD>Cover material</TD><TD>Tempered glass</TD></TR><TR><TD>Light emitting surface material</TD><TD>Glass</TD></TR><TR><TD>Glow Wire Test according to IEC 60695–2–12</TD><TD>650 °C</TD></TR><TR><TD>Mercury content</TD><TD>0.0 mg</TD></TR></TBODY></TABLE></FIGURE> Application & Mounting <FIGURE class=„table“><TABLE><TBODY><TR><TD>Ambient temperature range</TD><TD>-30…+45 °C</TD></TR><TR><TD>Temperature range at storage</TD><TD>-40…+70 °C</TD></TR><TR><TD>Type of connection</TD><TD>Cable, 3-pole</TD></TR><TR><TD>Type of protection</TD><TD>IP65</TD></TR><TR><TD>Protection class IK (shock resistance)</TD><TD>IK08</TD></TR><TR><TD>Dimmable</TD><TD>No</TD></TR><TR><TD>Mounting type</TD><TD>Surface</TD></TR><TR><TD>Mounting location</TD><TD>Wall, Pole, Floor</TD></TR><TR><TD>Application environment</TD><TD>Outdoor</TD></TR><TR><TD>Adjustable</TD><TD>Yes</TD></TR><TR><TD>Replaceable light source (EPREL)</TD><TD>Not replaceable</TD></TR><TR><TD>With light source</TD><TD>Yes</TD></TR></TBODY></TABLE></FIGURE> Lifespan <FIGURE class=„table“><TABLE><TBODY><TR><TD>Lifespan L70/B50 at 25 °C</TD><TD>50000 h 1)</TD></TR><TR><TD>Lifespan L80/B10 at 25 °C</TD><TD>35000 h 1)</TD></TR><TR><TD>Lifespan L90/B10 at 25 °C</TD><TD>25000 h</TD></TR><TR><TD>Number of switching cycles</TD><TD>100000</TD></TR></TBODY></TABLE></FIGURE>
- t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
Certificates & Standards <FIGURE class=„table“><TABLE><TBODY><TR><TD>Standards</TD><TD>CE, CB, EAC</TD></TR><TR><TD>Luminaire with limited surface temperature, „D sign“</TD><TD>No</TD></TR><TR><TD>Ball shot safe</TD><TD>No</TD></TR></TBODY></TABLE></FIGURE> PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS <FIGURE class=„table“><TABLE><TBODY><TR><TD>Minimum rate of recycled material in packaging</TD><TD>80 % 1)</TD></TR><TR><TD>Minimum percentage of recycled content in the product</TD><TD>0 % 1)</TD></TR><TR><TD>Product recyclability</TD><TD>Mostly recyclable product 1)</TD></TR><TR><TD>Packaging recyclability</TD><TD>Mostly recyclable packaging 1)</TD></TR><TR><TD>List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage</TD><TD>No</TD></TR><TR><TD>Contains substances of very high concern in concentrations greater than 0.1% by mass percentage</TD><TD>No</TD></TR></TBODY></TABLE></FIGURE>
- According to AGEC Decree 2022–748 (French Anti-Waste-Legislation for a Circular Economy)
