Параметри и описание
<FIGURE class=„table“><TABLE><TBODY><TR><TD> Reversible Modules for Hassle-Free Building
Plug it in whichever way you hold the reversible modules, removing the guesswork from your installation. </TD><TD> Perfect Alignment, Every Time
Simply follow the arrows to lock your fans into place for a secure, uniform look that stays perfectly aligned. </TD></TR></TBODY></TABLE></FIGURE><FIGURE class=„image image_resized“></FIGURE>
<FIGURE class=„table“><TABLE><TBODY><TR><TD> Smooth Fluid Dynamic Bearings
Fluid dynamic bearings with an extended shaft ensure quiet, vibration-free operation by optimizing pressure distribution </TD><TD> SOTA Microcontroller
Reduces motor noise, balances load fluctuations, and provides essential protection against inrush currents and reverse polarity </TD><TD> Optimized Gap Dimensions
Precision gap dimensions enable higher static pressure and peak airflow efficiency. </TD></TR></TBODY></TABLE></FIGURE><FIGURE class=„image image_resized“></FIGURE>
Technical Specifications General Specifications
Operating Ambient Temperature
0–40 °C
Dimensions
140 (L) x 140 (W) x 28 (H) mm
Weight
261 g
Fan Specifications
Fan Speed
400–2500 rpm
0dB below
5 %
Airflow | Airflow
110 cfm | 186 m³/h
Static Pressure
5.4 mm H20
Bearing
Fluid Dynamic Bearing
Current | Voltage
0.39 A | 12 V DC
Start-up Voltage
5 V DC
Connector
4-Pin PWM-Connector
RGB Specifications
LED Amount
16
Current | Voltage
0.6 A | 5 V DC
RGB Type
A-RGB
Connector
3-Pin A-RGB-Connector
